Pre-made spout pouch bags are placed in the notch of filling mechanism in the Auto Run mode. These pouched are filled automatically and operator can place the cap on the spout, After that Pouches are moved to cap tightening station automatically with preset time as per the operator skill. Caps are get tight and discharged on the small conveyor provided underneath of the filling station. There are two number of capping head provided to increase the speed of the filling operations.
Model : GFE 07
Power : 1.2 kw
Voltage : 220 V 50 Hz
Dimension : 2500x900x2108 mm
Filling volume : 100mm to 1000 ml
Accuracy : 1 %
Pouch type : premade standy spout pouch
Product : viscous or semi viscous as per the customer need.
Filling temp : 25 deg to 90 deg
Hopper : 60 lit capacity, single wall For the special need customer has to define need of jacketed hopper
