Original-C Automatic Clipping Machine (VAC 992)


Diaphragm Valve
Product Enquiry

Special Features

“Original-C“ automatic clipping machine to close and separate machine-usable nets fully automatically.

Download Leaflet VAC 992

Supplementary Equipment
  • Label dispenser
  • Thermo-barcode printer
  • Label dispenser
  • V - Belt


Diaphragm Valve
Diaphragm Valve


Technical Data
  • Performance : Max. 25 Packs/min (depending on type of film band and product)
  • Power supply : 230/400 Volt N/PE, 50 Hz, approx. 1.5 kW (other connections on request)
  • Compressed air : 6 bar, approx. 4,5 I/pack
  • Machine weight : Approx. 700 kg
  • Package weights : 0,5– 3kg (depending on product size)
  • Length of PE-film band : variable
  • Inside net tube diameter : 65 - 190mm (others on request)
Standard Equipment
  • Automatic net tube change for continuous operation
  • Net length infinitely adjustable
  • Net draw-off by means of net transport rollers
  • Two transporting units for PE-film bands with cutting device
  • Length of the PE-film bands electronically adjustable
  • Microprocessor control with twolined clear text display
  • Memory for 15 programms
  • Net charging cone, net tube stand to allow a quick net tube exchange
